The Unite U-TC-G series dry gas filters are primarily used for filtering finedust particles from gases.
They utilize ultra-fine, multi-layered glassfiber or polyester fiber to achieve the highest filtration accuracy andpermeability. The high performance of these filters is crucial forprotecting downstream precision equipment in gas processing andtransportation systems.
Easy cleaning and maintenance process
Pressure leaf filters are highly efficient, reliable, versatile, andenvironmentally sustainable, making them an indispensable tool inindustrial filtration processes. Their main advantages include improvedproduct quality, increased production efficiency, and compliance withregulatory standards.
Scalable Filtration Area: The horizontal orientation of the leaves(vertically stacked) provides a scalable surface area for maximumfiltration efficiency.
Continuous, Closed Operation: The system can be designed for filling,filtration, discharge, and cleaning without interrupting the filtrationprocess.
Robust Versatility: Pressure leaf filters are commonly used in a widerange of chemical and pharmaceutical industries and applications,making them a preferred choice for filtration.
Housing Material: 20#, 16Mn, 16MnR, 304, 316L
Filter Element Material: Metal pleated type, Fiber pleated type
Filtration Accuracy: 5μm ~ 300μm
Filtration Efficiency: Above 99%
Working Pressure: 0.1~40.0 Mpa
Working Temperature: -30~300℃
Applicable Media: Natural gas, manufactured gas, liquefied petroleumgas, associated petroleum gas, etc.
Manufacturing Standard: GB150, ASME filter
Installation Method: Vertical, Horizontal
Inlet and Outlet Installation Direction: Horizontal, Vertical
pre-coated filters are
fully automatic backwashing filters have
